| Fingerprint Capacity | 1000 (2000 without SSR) |
| ID Card Capacity | 1000 (Optional) |
| Record Capacity | 80,000 |
| Display | 2.8-inch TFT Screen |
| Communication | TCP/IP, USB Host |
| Standard Functions | WDMS,Web Server, SMS, Automatic Status Switch,Self-Service Query, Work Code, T9 input, 9 Digits User ID, DST, Schedule Bell |
| Optional Functions | ID/Mifare |
| Software | ZKTime.net 3.0 |
| Power Supply | DC 12V 1.5A |
| Verification Speed | 0.5 sec |
| Operating Temp. | 0 °C- 45 °C |
| Operating Humidity | 20%-80% |
| Dimensions | 184 x 136 x 37.6 (Length x Width x Thickness) |
