| User Capacity | 3000 |
| Fingerprint Capacity | 3000 |
| ID Card Capacity | 3000 optional |
| Record Capacity | 50,000 |
| Display | 2.8’’ color screen |
| Communication | TCP/IP, WiFi, USB-host |
| Standard Functions | 9 Digit User ID, T9 Input, SMS, DST, Self-Service Query, Automatic Status Switch, Ring bell, ADMS |
| Optional Functions | ID/Mifare, RS232 External Printer |
| Access Control Interface | 3rd Party Electirc Lock, Exit Button |
| Software | BioTime |
| Power Supply | DC 12V/1.5A |
| Dimension | 185*137*38.2mm (LxWxT) |
| Operating Temp | 0 °C - 45 °C |
| Operating Humidity |
20% - 80% |
Warranty one year
