General
Weight About 210g (Scanner); 235g (Base receiver)
Cable Length 1.8m
Interface Type 2.4G, Standard USB (Full Speed ,USB 2.0)
Material ABS+PC
Color Black
User indicators LED, buzzer
Scanning Performance
Light source Visible laser diode, wavelength: 525nm
Processor ARM 8-bit
Startup time 4s
Analytical ability 1D: ≥3mil/0.076mm@PCS90%
Depth of focus 0-50cm
Scanning mode Manual scanning, automatic scanning
Reading angle Roll: ±30°; Pitch: ±60° (or greater); Yaw: ±50° (or greater)
Power 85mA , 5V DC
Decode capabilities UPC-A, UPC-E, EAN-8, EAN-13, ISSN, ISBN, Code 128, GS1-128, ISBT 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5 (IATA), Codabar (NW-7), Plessey.
Wireless performance
Wireless standard 2.4GHz (IMS)
Transmission distance 150m (Outdoor open environment)
Storage capacity 100000 commodity codes (16MB)
Battery capacity 1600mAh
Battery charging time About 5 hours
Continuous working hours ≥20hours
