Dispaly Backlight |
DLED backlight |
|
|
Resolution |
Native 4K (3840 x 2160 pixels) , UHD |
|
|
Brightness |
350 cd/㎡ |
|
|
Contrast |
1200:1 or higher |
|
|
Screen Size(mm) |
1895.04*1065.96 |
|
|
Aspect Ratio |
16:9 |
|
|
View Angle |
178° |
|
|
Screen Mode |
16:9/4:3/dot to dot/full screen |
|
|
Color Depth |
10bit, 1.07Billon colors |
|
|
Panel Response Time |
8ms |
|
|
Support Resolution |
4K Ultra HD 3840x2160 |
|
|
AG Tempered Glass |
tempered glass, 4mm thickness, anti-reflective, shock and scratch resistant.7H hardness |
|
|
Android Specification |
Android 14.0 |
|
|
8x ARM Cortex-A55 |
||
|
Quad-core Mali G52 |
||
|
Support Wi-Fi 5 802.11 a/b/g/n/ac |
||
|
Bluetooth® 5.0 |
||
|
Ethnet: 10/100M |
||
|
Ram: 4G |
||
|
Storage: 32G |
||
|
Full support for 4K UHD relosution (with OPS slot working with 4k 60Hz); |
||
|
The file manager is supported |
||
|
Screen sharing application is supported |
||
|
Android IWB app: |
Yes, built in |
|
|
• Connectors |
Ports on the front bezel : 1 x HDMI, 3 x USB-A 2.0 , 1 x USB-B (Touch) Rear Ports: Input ports : 1*HDMI, 1*VGA&AUDIO IN, 1*USB-A 3.0, 1*TOUCH-USB, 1*RS232, 1*RJ45IN, 1*MICIN, 1*OPS SLOT Output ports: 1*HDMI-out, 1*COAXIAL, 1*Earphone |
|
|
Front Button |
POWER |
|
|
Light Sensor |
support automatically adjusts the brightness of the panel according to ambient light. |
|
|
Voltage |
AC(100～240)V-50/60HZ |
|
|
Speaker |
15Wx2 |
|
|
Power Range |
Standby Power<1W (Rated Power<250W) |
|
|
Touch Parameter |
Touch Technology |
Infared Touch |
|
Touch Points |
Touch Points |
|
|
Writing Mode |
Finger or any opaque object, The use of the deviceby2userssimultaneously will be guaranteed. |
|
|
Accuracy |
<2mm |
|
|
Response Time |
5ms |
|
|
Cusor Speed |
>180 dot/s |
|
|
Connection Port |
USB 2.0, USB 3.0 |
|
|
Operating System |
Windows/Linux (include Max OS :Madrid Linux) /Mac OS/Android/Chrome OS |
|
|
Working Temperature |
0℃-40℃ |
|
|
Accessories |
Magnetic Pen*2, HDMI Cable *1, Touch USB Cable *1 , Power Cable*1, Software downloadcard*1,Remoter*1, Wall mounting bracket with Installation Guide included *1 |
|
|
Product sizes(mm) |
1485*905*85 |
|
|
Product N.W. /G.W (kg) |
37/49 |
|
|
Carton Size |
1646*1043*160 |
|
