FEATURES
- Form Factor
- Counter Top
- Features & Benefits
- Integrated EAS
- Power-over USB
- Soft White LED Illumination
- Adaptus™ 6.0 Area-Imaging Technology
DIMENSIONS
- Overall Dimensions
- 14.8 x 15.2 x 8.5 cm
- 5.83 x 5.98 x 3.35 in
SCANNING SPECIFICATIONS
- Decode Capability
- 1D
- Postal
- 2D
- OCR
- Pitch
- 65
- Skew
- 75
- Maximum Brightness
- 100,000
- Scan Pattern
- Area Image
- Motion Tolerance
- 13 mil at optimal focal point
- Scanning Range
- Presentation (0 ft to 10 ft (0 mm to 255 mm))
- Print Contrast
- 25
HARDWARE
- Engine Type
- 2D
- Host System Interface
- KBW
- USB
- RS485
- RS-232
ELECTRICAL
- Sleep Mode Current
- 210
- Input Voltage
- 5 - 5.2 V DC
- Standby Current
- 270 mA
ENVIRONMENTAL
- Storage Temperature Range
- - 4 - 140 °F
- - 20 - 60 °C
- Operating Temperature
- 0 - 40 °C
- 32 - 104 °F
- Operating Humidity
- 5 - 95 %
STANDARDS & APPROVALS
- Protection Ratings
- IP5X
SERVICE TERMS
-
Warranty Duration
-
3 yr
