Print method |
Direct thermal |
|
Print command |
Compatible with ESC/POS commands |
|
Resolution |
203DPI |
|
Print speed |
300mm/s |
|
Print width |
72mm |
|
Print head temperature detect |
Thermal sensitive resistance |
|
Print head position detect |
Microswitch |
|
Black mark sensor |
Reflective sensor |
|
Paper detect |
Transmissive sensor |
|
Memory |
FLASH:60K |
|
Interface |
Standard: USB+Ethernet+Serial |
|
Graphics |
Support different density bitmap printing |
|
Bar code |
UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ITF/CODABAR/CODE39/CODE93/CODE128/QRCODE |
|
Character set |
Standard GB18030 Simplified Chinese |
|
Character enlargement/rotation |
1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing |
|
Media type |
Thermal roll paper |
|
Media width |
79.5士0.5mm |
|
Media thickness |
0.06-0.08mm |
|
Media roll outer diameter |
Max. 83mm |
|
Media output method |
Top paper output, partial-cut |
|
Power supply |
Input: DC24V 2.5A |
|
Working environment |
0~40℃, 30%~90% non-condensing |
|
Storage Environment |
-20~55℃, 20%~93% non-condensing |
|
Printer weight |
1.25kg |
|
Printer dimension |
180.6mm×139mmX127mm |
|
Print head (reliability) |
50km |
|
Printer certificate |
CCC, CE, FCC, RoHS |
