Hardware Specifications
Total Network Interfaces 24x GE RJ45 and 4x 10GE SFP+
Dedicated Management 10/100 Port 0
RJ-45 Serial Console Port 1
Form Factor 1 RU Rack Mount
Power over Ethernet (PoE) Ports 24 (802.3af/at)
PoE Power Budget 370 W
Mean Time Between Failures > 10 years
Switching Capacity (Duplex) 128 Gbps
Packets Per Second (Duplex) 190 Mpps
MAC Address Storage 32 K
Network Latency < 1µs
VLANs Supported 4 K
Link Aggregation Group Size 8
Total Link Aggregation Groups 128
DRAM 512 MB DDR3
FLASH 64 MB
Packet Buffers 2 MB
Power Required 100–240V AC, 50–60 Hz
Power Supply AC Built in
Power Consumption (Average / Maximum) 449.8 W / 451.3 W
Warranty one year
