Lenovo ThinkPad E16 Gen3 Ultra 7-255H/16GB/512GB

Processor

1. Intel® Core™ Ultra 5 225U Processor (E-cores up to 3.80 GHz P-cores up to 4.80 GHz with Turbo Boost, 12 Cores, 14 Threads, 12 MB Cache)
2. Intel® Core™ Ultra 7 255H Processor (E-Core Max 4.40 GHz, P-Core Max 5.10 GHz with Turbo Boost, 16 Cores, 16 Threads, 24 MB Cache)

Operating System

1. Windows 11 Pro — Lenovo recommends Windows 11 Pro for business
2. Windows 11 Home

Neural Processing Unit (NPU)

Up to 13 trillion operations per second (TOPS) AI performance

Graphics

1. Intel® Arc™ 140T Graphics (with H Series processor)
2. Intel® Integrated Graphics (with U Series processor)

Memory

Up to 32GB DDR5, (5600Mhz), SODIMM

Storage

Up to 1TB M.2 PCIe Gen4 SSD (2242)

Battery

48Whr

Audio

1. 2 x 2W speakers
2. Harman Kardon® speakers
3. Dolby Atmos®
4. Dual-array mics

Camera

1. Hybrid FHD 1080p & infrared (IR) with webcam privacy shutter
2. 5M RGB with webcam privacy shutter

Connectivity

Ports/Slots

1. USB C® (Thunderbolt™ 4, USB 40Gbps) with power delivery 3.1 & DisplayPort 2.1
2. USB-C® (USB 20Gbps) with power delivery 3.1 & DisplayPort 1.4
3. USB-A (USB 10Gbps)
4. USB-A (USB 5Gbps)
5. Ethernet (RJ45)
6. HDMI® 2.1 (supports resolution up to 4K@60Hz)
7. Headphone / mic combo

USB port transfer speeds are approximate and depend on many factors, such as processing capability of host/peripheral devices, file attributes, system configuration and operating environments; actual speeds will vary and may be less than expected.

Wireless

1. Intel® WiFi 6E* 802.11AX (2 x 2)
2. Bluetooth® 5.3

* 6GHz WiFi 6E operation is dependent on the support of the operating system, routers/APs/gateways that support WiFi 6E, along with the regional regulatory certifications and spectrum allocation.

Supported Docking

1. USB-C® 3.0 dock
2. USB-C® Thunderbolt™ 4 dock

Design

Display

1. 16” WUXGA (1920 x 1200) IPS, 16:10 aspect ratio, 300nit, 60Hz, 45% NTSC, 90.7% STBR, antiglare, TÜV Low Blue Light (software controlled)
2. 16” WUXGA (1920 x 1200) IPS, 16:10 aspect ratio, 300nit, 60Hz, 45% NTSC, 90.7% STBR, antiglare, TÜV Low Blue Light (software controlled), touchscreen

Dimensions (H (front-to-back) x W x D)

10.10 – 17.05mm x 356mm x 249mm / 0.40 – 0.67” x 14.02” x 9.80”

Weight

Starting at 1.63kg / 3.59lbs

Keyboard

1. Dual-function TrackPoint: navigate cursor or double-tap to open TrackPoint Quick Menu
2. Optional: backlit with white LED lighting
3. Spill-resistant
4. TrackPad with 3 buttons (115mm x 67mm / 4.52" x 2.63”)
5. ThinkPad TrackPoint Keyboard (1.5mm / 0.05” key travel)

Color

Eclipse Black

Sustainability

Material

1. 90% post-consumer content (PCC) recycled plastic used in speaker enclosure
2. 90% PCC recycled plastic used in battery enclosure
3. 90% PCC recycled plastic used in adapter
4. 85% PCC plastic used in backlit keycaps
5. 70% PCC plastic used in non-backlit keycaps
6. 50% recycled aluminum used in top (A) cover & bottom (D) cover
7. 50% PCC recycled plastic used in display side (B)
8. Bamboo fiber used in device bag
9. Forest Stewardship Council® (FSC)-certified carton & accessory box
10. FSC- certified paper screen sheet

Certifications / Registries

1. ENERGY STAR® 9.0
2. MIL-STD-810H
3. TCO 10.0 certified
4. TÜV Low Blue Light (software controlled)
5. TÜV Eyesafe®
6. EPEAT® Gold with Climate+
